外形尺寸(mm) | 額定負荷(kN) | 極限轉(zhuǎn)速(rmp) | 軸承型號 | |||||||
Grease | Oil | YJ | ||||||||
d | D | B | r smin | Cr | Cor | Noncontact | contact | Open | Closed | |
12 | 28 | 8 | 0.3 | 5100 | 2370 | 28000 | 18000 | 32000 | 6001 | |
12 | 32 | 10 | 0.6 | 6800 | 3050 | 22000 | 17000 | 28000 | 6201 | |
12 | 37 | 12 | 1.0 | 9700 | 4200 | 20000 | 16000 | 24000 | 6301 | |
15 | 32 | 8 | 0.3 | 5600 | 2840 | 24000 | 15000 | 28000 | 1600/P6 | |
15 | 32 | 9 | 0.3 | 5600 | 2840 | 24000 | 15000 | 28000 | 6002 | 6002-RS/P5 |
15 | 35 | 11 | 0.6 | 7650 | 3750 | 20000 | 14000 | 24000 | 6202 | 6202-RS/P6 6202-2Z/P6 |
15 | 42 | 13 | 1.0 | 11400 | 5450 | 17000 | 13000 | 20000 | 6302/P5 | |
17 | 35 | 8 | 0.3 | 6000 | 3250 | 22000 | 13000 | 26000 | 16003 | |
17 | 35 | 10 | 0.3 | 6000 | 3250 | 22000 | 13000 | 26000 | 6003 | |
17 | 40 | 12 | 0.6 | 9550 | 4800 | 17000 | 12000 | 20000 | 6203 | |
17 | 52 | 12 | 1.1 | 15900 | 7900 | 13000 | 9500 | 16000 | 6304-17W12 | |
17 | 47 | 14 | 1.0 | 13600 | 6650 | 15000 | 11000 | 18000 | 6303 | |
20 | 42 | 12 | 0.6 | 9400 | 5000 | 18000 | 11000 | 20000 | 6004 | |
20 | 43 | 12 | 0.6 | 9400 | 5000 | 18000 | 11000 | 21000 | 6004D43 | |
20 | 47 | 12 | 1.0 | 12800 | 6600 | 14000 | 10000 | 18000 | 6204W12 | |
20 | 48 | 14 | 1.0 | 12800 | 6600 | 14000 | 10000 | 18000 | 6204D48 | |
20 | 52 | 12 | 0.6 | 10100 | 5850 | 12000 | 8500 | 16000 | DG205212-3 | |
20 | 52 | 12 | 1.0 | 12800 | 6650 | 13000 | 9500 | 16000 | 6304B12 | |
20 | 52 | 12 | 1.1 | 15900 | 7900 | 13000 | 9500 | 16000 | 6304W12 | |
22 | 44 | 12 | 0.6 | 9400 | 5050 | 10000 | 17000 | 20000 | 60/22-2RS | |
22 | 50 | 14 | 1.0 | 13900 | 6950 | 9000 | 13000 | 17000 | 60/22 | |
23 | 56 | 15 | 1.1 | 20790 | 10520 | 12000 | 9000 | 15000 | 66/23 | |
25 | 52 | 13 | 1.0 | 14000 | 7900 | 12000 | 8500 | 16000 | 6205EX2 | |
25 | 62 | 12 | 0.6 | 22200 | 11500 | 12000 | 8500 | 16000 | 529371 | |
25.5 | 58 | 16 | 1.0 | 20560 | 11120 | 12000 | 8500 | 16000 | 66/25.5-2RS | |
28 | 58 | 16 | 1.0 | 17915 | 9798 | 12000 | 8000 | 14000 | 62/28 | |
28 | 68 | 18 | 1.1 | 26700 | 14000 | 10000 | 7500 | 13000 | 63/28 | 63/28-RS |
30 | 55 | 13 | 1.0 | 16000 | 10300 | 11000 | 6700 | 13000 | 6006 | |
35 | 62 | 9 | 0.5 | 11700 | 5200 | 11000 | 6700 | 13000 | 16007 |
